Agressivo em subidas e incríveis descidas, o E-Vertic FX-Type reage perfeitamente em qualquer trilha que seu amor pelo off-road o leve.
Andar em terrenos acidentados com quedas inferiores a 122 cm.
MOTOR
Bosch Performance CX BES3 motor unit
BATTERY
Bosch Powertube 750wh integrated battery, w/Kiox display
FRAME
e-VERTIC FX-Type FULL SUSPENDED ALU sizes: 43-48-53 - 140 mm front travel - 55 mm rear travel - Fender + Rack mounting points - HT 1,5"" straight - for integrated cable routing - Seatpost 31,6 mm - 12x148 mm dropouts - Set dropout (sx+dx) TA 148mm externa
FORK
Fox 34 Float Rhythm, Sweep Adjust, 140 mm travel, 44 rake, boost 15x110 mm QR axle
REARSHOCK
Rock Shox Deluxe Select, 210/55, DebonAir Linear, Shaft 25x8
HEADSET
Acros 1.8" top / 1.5" bottom - bearings - internal cable routing - w/ blocklock
SHIFTERS
Sram SL NX MMX EAGLE SINGLE CLICK TRIGGER
REAR DERAILLEUR
Sram RD GX EAGLE LUNAR
CRANKSET
FSA Direct Mount Steel Chainring - 34T / w/HT Steel CK-320 FSA E-Bike Diecast Crankset - ISIS / 170mm / Die cast aluminum
BOTTOM BRACKET
included in the motor
CHAIN
Sram CN GX EAGLE 126LI PWR.LCK 12Sp
CASSETTE
Sram CS XG 1275 EAGLE 10-52T
BRAKES
MT Thirty ,front banjo 4 piston caliper/ rear 0° 2 piston caliper, Magura Shiftmix 4 for left-front, I Spec-EV compatible Magura Shiftmix 3 for right-rear
ROTOR
Magura Centerlock - 203 mm
REARHUB
Formula, CENTER LOCK, J-BEND, THRU-AXLE, W/O QR, FOR SRAM XD DRIVER 11-SPEED
FRONTHUB
Formula, DISC HUB, CENTER LOCK, J-BEND, THRU-AXLE, W/O QR, 15x110
TIRE
Continental Ruban black/black foldable skin SL
STEM
Velomann , 50 mm, 35 mm, 1"1/8
HANDLEBAR
Velomann, width 780mm diam.35mm, rise 20mm, backsweep 9°, double butted AL7050 l
GRIPS
T-One Rock T-GP34 single lock grip , TPR, plastic inner body, aluminium clamp
SEATPOST
Alpha1 Series - 31.6 mm - Remote RM07 I-Spec EV - 1800 mm cable length - Velomann logo 125 mm - for size M 150 mm - for size L/XL
SADDLE
Fi`zi:k Terra Aidon X5 - 160mm - fiber reinforced nylon with Wingflex - S-Alloy Mobius 7x7mm
E-Vertic FX Type | |||||||||||||
Size | A | B1 | C | D | E | F | G | G1 | H | I | X | Y | WB |
M | 438 | 611 | 461 | 25 | 120 | 794 | 77° | 65° | 44 | 559 | 467 | 622 | 1254 |
L | 480 | 636 | 461 | 25 | 130 | 822 | 77° | 65° | 44 | 559 | 490 | 631 | 1281 |
XL | 530 | 659 | 461 | 25 | 145 | 848 | 77° | 65° | 44 | 559 | 510 | 645 | 1307 |
