MOTOR UNIT
MOTOR
Bosch Performance Line CX, 250W, 85Nm, Purion display
BATTERY
Bosch PowerTube 625Wh integrated battery
FRAMESET
FRAME
e-OMNIA FX-Type ALU sizes: 43, 48, 53 - 12x148 mm thru axle dropouts (special dropout for external derailleur) - Post mount 180 disc brake type - 160/150mm travel front - 150mm travel rear
FORK
Fox 36 Float eBike optimized 29", Rhythm, 160mm travel, 1.5" tapered HT, QR 15x110mm BOOST axle, minimum 180mm rotor, maximum 230mm rotor, 44mm rake, 58mm crown
REARSHOCK
FOX Float, Performance, 185/55, EVOL, 3 position lever, 0.3 Spacer, Neutral Decal
HEADSET
FSA NO.55R/558 1.5"
DRIVETRAIN
SHIFTERS
Shimano, SL-M6100-IR, DEORE,12-SPEED
REAR DERAILLEUR
Shimano, RD-M8100, XT, SGS 12-SPEED
CRANKSET
FSA CK-762/IS Forged Alu crank 165 mm ISIS Shimano CHAINRING, SM-CRE80-12, 34T
BOTTOM BRACKET
included in the motor
CHAIN
Shimano, CN-M7100, 12sp
BRAKES
BRAKES
Shimano, BL-MT501, BR-MT520, 4 pistons
ROTOR
Shimano, SM-RT64, RT-EM600, DEORE, L 203MM
WHEELS
WHEELS
Velomann E30 Tubeless Ready 29", 622x30, 32 hole
REARHUB
Formula CL-3248 for Center Lock, 32h, 12x148mm TA
FRONTHUB
Formula CL-811 for Center Lock, 32h, 15x110mm TA
TIRE
Front: Pirelli Scorpion E-MTB M 29x2.6 TLR, 60tpi Rear: Pirelli Scorpion E-MTB R 27.5x2.6 TLR, 60tpi
COCKPIT
STEM
Velomann +/-0°, 1,1/8 x diam.35mm, 50mm
HANDLEBAR
Velomann, width 780mm, diam.35mm, rise 18mm, backsweep 8°
GRIPS
T-One Rock T-GP34 single lock grip, TPR, 130mm, plastic inner body, aluminium clamp
SADDLE
SEATPOST
Velomann, diam.31,6mm, internal remote cable routing, 120mm/150mm travel
SADDLE
Velomann Gnd Full-fit Start Up, carbon steel rail, 262x145
ACCESSORIES
FRONTLIGHT
Spanninga custom integrated light, 40 lux
REARLIGHT
Spanninga custom integrated light
