MOTOR UNIT
MOTOR
Shimano EP8, 250W, 85Nm, Display SC-EM800
BATTERY
Integrated battery 630Wh
FRAMESET
FRAME
T-Tronik FX-Type Pro carbon sizes: 40, 44, 48, 52 - 12x148 mm thru axle dropouts - Post mount 180 disc brake type - 150mm travel front & rear - Internal cable routing in DT
FORK
RockShox YARI RC 29", 150mm travel, 1.5 tapered HT, Maxle Stealth 15x110mm BOOST axle, minimum 180mm rotor, maximum 220mm rotor, 42mm rake, 59mm crown
REARSHOCK
Fox Float DPS Performance, LV, EVOL, 3 position Lever
HEADSET
FSA NO.77R 1.5"
DRIVETRAIN
SHIFTERS
Shimano Deore SL-M6100, 12sp
REAR DERAILLEUR
Shimano Deore XT RD-M8100, 12sp
CRANKSET
Shimano FC-EM600, 165MM Shimano Chainring SM-CRE80-12-B, 34T
CHAIN
Shimano, CN-M6100
BRAKES
BRAKES
Shimano, BL-M6100, BR-M6120, 4 pistons
ROTOR
Shimano SM-RT64, RT-EM600, L 203MM
WHEELS
WHEELS
Velomann 29", 622x30, 32 hole
REARHUB
Shimano FH-MT510-B, for Center Lock, 32h, 12x148 TA
FRONTHUB
Formula CL-811 for Center Lock, 32h 15x110mm TA
TIRE
Kenda Hellkat 29x2.6, 60tpi, 66-622
COCKPIT
STEM
Velomann +/-0°, 1,1/8 x diam.35mm, 50mm
HANDLEBAR
Velomann width 780mm, diam.35mm, rise 20mm, backsweep 9°
GRIPS
T-One Rock T-GP34
SADDLE
SEATPOST
JD, diam.31,6mm, internal remote cable routing 100m travel --> size 40 125m travel --> size 44 150m travel --> sizes 48, 52
SADDLE
Fizik Alpaca Terra, S alloy rail, 249x145
