MOTOR UNIT
MOTOR
Bosch Performance Line CX, 250W, 85Nm, Purion display
BATTERY
Bosch PowerTube 625Wh integrated battery
FRAMESET
FRAME
e-OMNIA X-Type ALU sizes: 43, 48, 53 - 12x148 mm thru axle dropouts (special dropout for external derailleur) - Post mount 180 disc brake type - 120mm travel front
FORK
RockShox Recon Silver RL 29", 120mm travel, 1.5" tapered HT, Maxle Stealth 15x110mm BOOST axle, minimum 160mm rotor, maximum 220mm rotor, 42mm rake, 61mm crown, Solo Air, extl rebnd, 32mm stanchions
HEADSET
FSA NO.55R/558 1.5"
DRIVETRAIN
SHIFTERS
Sram SX EAGLE 1x12
REAR DERAILLEUR
Sram SX Eagle, 12sp
CRANKSET
FSA CK-762/IS Forged Alu crank 165 mm ISIS Sram EAGLE 34T CHAINRING
BOTTOM BRACKET
included in the motor
CHAIN
Sram SX EAGLE, 12sp
BRAKES
BRAKES
Shimano, BL-M4100, BR-MT410
ROTOR
Shimano, SM-RT10, M 180MM
WHEELS
WHEELS
Velomann 29”, 30mm 29”
REARHUB
Formula CL-3248 for Center Lock, 32h, 12x148mm TA
FRONTHUB
Formula CL-811 for Center Lock, 32h, 15x110mm TA
TIRE
Kenda Booster 29x2.6, 30tpi
COCKPIT
STEM
Velomann +/-0°, 1,1/8 x diam.31,8mm, 55mm
HANDLEBAR
Velomann, width 740mm, diam.31.8mm, rise 15mm, backsweep 9°
GRIPS
T-One Rock T-GP34 single lock grip, TPR, 130mm, plastic inner body, aluminium clamp
SADDLE
SEATPOST
Velomann, lenght 350mm for SM size and 400mm for MD, LG, diam.31,6mm, 0mm seatback
SADDLE
Velomann Gnd Full-fit Start Up, carbon steel rail, 262x145
ACCESSORIES
FRONTLIGHT
Spanninga custom integrated light, 40 lux
REARLIGHT
Spanninga custom integrated light
