MOTOR UNIT
MOTOR
Bosch Performance Line CX, 250W, 85Nm, Kiox display
BATTERY
Bosch Powertube 750Wh integrated battery
FRAMESET
FRAME
e-VERTIC FT-Type ALU sizes: 43, 48, 53 - 12x148 mm thru axle dropouts - Post mount 180 disc brake type - 140mm travel front & rear - Internal cable routing in steerer
FORK
Sram RockShox Recon Silver RL 29", 140mm travel, 1.5" tapered HT, Maxle Lite 15x110mm BOOST axle, minimum 160mm rotor, maximum 220mm rotor, 42mm rake, 61mm crown, Solo Air, extl rebnd, 32mm stanchions
REARSHOCK
RockShox Deluxe Select, 210/55, DebonAir Progressive, Damper Type R, Compression tune L, Lockout Force n/a, black finish tube, external rebound adjustment, Volume reducer 0 Neg 2 Pos
HEADSET
Acros AZX-670 1.8" top / 1.5" - internal cable routing
DRIVETRAIN
SHIFTERS
Sram SX EAGLE 1x12
REAR DERAILLEUR
Sram SX Eagle, 12sp
CRANKSET
FSA CK-320/IS/Gen4 FSA E-Bike Diecast Crankset ISIS / 165mm / Die cast aluminum
BOTTOM BRACKET
included in the motor
CHAIN
Sram SX EAGLE, 12v
BRAKES
BRAKES
Shimano, BL-M4100, BR-MT420, 4 pistons
ROTOR
Shimano, SM-RT30, L 203MM
WHEELS
WHEELS
Velomann E-Sport Tubeless Ready 29", 25-622, 32 hole
REARHUB
Formula CL-3248 for Center Lock, 32h, 12x148mm TA, HG, 2SB
FRONTHUB
Formula CL-811 for Center Lock, 32h, 15x110mm TA
TIRE
Schwalbe SUPERMOTO perf DD.raceguard 62-622 (29x2.4)
COCKPIT
STEM
Velomann, 50mm, 35mm, 1"1/8
HANDLEBAR
Velomann, width 780mm, diam.35mm, rise 18mm, backsweep 8°
GRIPS
T-One Rock T-GP34 single lock grip, TPR, 130mm, plastic inner body, aluminium clamp
SADDLE
SEATPOST
Velomann, lunghezza 350 mm per la taglia SM e 400 mm per la MD, diametro 31,6 mm, schienale 0 mm
SADDLE
Velomann 260x160mm, 365gr.
ACCESSORIES
PEDALS
Fasten, w/ED steel cage, Boron ED black axle, BS reflector
MUDGUARDS
Racktime Alumee 72mm, 28"
KICKSTAND
Bianchi Custom
REARCARRIER
Racktime luggage stay set, 29", Max load 15Kg
FRONTLIGHT
Lezyne, 115 lux, 310 lumen
REARLIGHT
Trelock RearLight MudGuard Ebike6-12V
