MOTOR UNIT
MOTOR
Bosch Performance Line CX, 250W, 85Nm, Kiox display
BATTERY
Bosch Powertube 625Wh integrated battery
FRAMESET
FRAME
E-OMNIA C-Type chain drive ALU sizes: 45-50-55 - 9x135 mm quick release dropouts (special dropout for external derailleur) - Post mount 180 disc brake type - Internal cable routing in DT - Frame lock compatible - 625Wh compatible - custom rear carrier int
FORK
Suntour XCM34-Boost LOR DS 29", 100mm travel, 1.5" tapered HT, w/ 15AH2-110 TA, minimum 160mm rotor, maximum 203mm rotor, 34mm stanchions
HEADSET
FSA NO.55R/558 1.5"
DRIVETRAIN
SHIFTERS
Shimano, SL-M4100-R, DEORE, 10-SPEED
REAR DERAILLEUR
Shimano, RD-M4120, DEORE, SGS 10/11-SPEED
CRANKSET
FSA Metropolis, Alloy, 170mm FSA Steel Chainring 38T
BOTTOM BRACKET
included in the motor
CHAIN
KMC e10S NPBK
BRAKES
BRAKES
Promax, DSK-925
ROTOR
Promax DSK-925, 180mm, center lock
WHEELS
WHEELS
Velomann E-Sport Tubeless Ready 29", 25-622, 32 hole
REARHUB
Formula CL-1422 Center lock, 32hole, 14G, O.L.D. 135mm AXEL145mm, for Shimano 8/9/10speed with Quick release QR22
FRONTHUB
Formula CL-811 for Center Lock, 32h, 15x110mm TA
TIRE
Vittoria e-Randonneur, 50-622
COCKPIT
STEM
Velomann 35,3D FORGED 0°>90° L70MM
HANDLEBAR
Velomann, 31.8*630 / Rise 34mm / Back Sweep 41°
GRIPS
Herrmans Grip
SADDLE
SEATPOST
Velomann 31.6*350, suspension seatpost
SADDLE
Velomann, 256x220, 612gr.
ACCESSORIES
PEDALS
VP, axle 7mm boron steel, EPB system, size 112x83,3mm, reflector included
MUDGUARDS
SKS PET Mudguards A65 R /28"
KICKSTAND
Velomann load 35kg
REARCARRIER
custom rear carrier integrated into the frame design
FRONTLIGHT
Spanninga custom integrated light, 40 luxt
REARLIGHT
Spanninga custom integrated light
