Com base na disponibilidade dos componentes, a Bianchi reserva-se o direito de fazer alterações nas especificações sem aviso prévio.

FRAMESET

FRAME

Arcadex Comp Disc Brake Specification: Flat Mount 140/160 Bottom Braket Standard: PressFit 86.5 X Ø41 Rear Axle: thru12 OLD (Over-Locknut-Dimension): 142 mm Front Derailleur:Non Compatible Rear Derailleur: SRAM UDH Hanger type Max Chainring Compatibility:

FORK

Bianchi Arcadex Fork Disc Brake Specification: Flat Mount 140/160 Front Axle: thru12 OLD (Over-Locknut-Dimension): 100 mm Tire Clearance: ETRTO 622-42mm Steer tube Diameter: 1 1/8"" Material: Epoxy - SM Carbon Fiber Composite

HEADSET

Bianchi Custom Acros ICR (Internal Cable Rounting) Spacers:5 mm x1, 10mm x3 Headtube Cover: Bianchi Costum Compresion Ring: 1.125 Inch Top Bearing: Angular contact Bearing 42x52x7 + seal Bottom Bearing: Angular contact Bearing 40x52x7 + seal

DRIVETRAIN

SHIFTERS

Shimano GRX 610 ST/BL-RX610

REAR DERAILLEUR

Shimano GRX 822 RD-RX822, SGS Maximum Cassette Sprocket 51T

CRANKSET

Shimano GRX 610 FC-RX610-1, 40T Crank Length: 170mm-XS(47)-SM(51), 172.5mm-MD(55)-LG(58), 175mm-XL(61)

BOTTOM BRACKET

Shimano SM-BB72-41B, press fit

CHAIN

Shimano CN-M7100

CASSETTE

Shimano CS-M7100-12 speed, 11-51T Driver body Interface: MicroSpline

BRAKES

BRAKES

Shimano Hydraulic Brake, BR-RX400

ROTOR

Shimano SM-RT70 IceTech Hub Interface: Centerlock Rotor Diameter: 160 mm (front&Rear)

WHEELS

WHEELS

Fulcrum RapidRed 900 2-Way Fit Ready (for clincher and tubeless ready) Rim Diameter: 700C Material: Aluminum Alloy Rim Height: 24 mm Inner Wigth Channel: 22 mm

TIRE

Pirelli Cinturato™ GRAVEL M Classic, 45-622 tan sidewall

COCKPIT

STEM

Velomann AICR Alloy Rise: -2° Steerer Diameter: 1-1/8"" (28.6mm) HB interface Diameter: 1-1/4"" (31.8mm) Stem Lengths: 80mm - XS(47), 90mm - SM(51), 100mm-MD(55), 110mm-LG(58),120m -XL(61)

HANDLEBAR

Velomann Gravel ICR Alloy Flare: 16° Drop: 130mm Reach 70mm Interface Diameter: 1 1/4"" (31.8mm) HandleBar Widths: 400 - SX(47) SM(51), 420 - MD(55) LG(58), 440 -XL(61)

GRIPS

Bianchi Hexagon tape 2.5mm thickness, Full black

SADDLE

SEATPOST

Velomann Carbon UD SeatPost O.D: Ø27.2 mm Seatpost lengths: 300mm-SX(47), 350mm- SM(51) MD(55), 400mm-LG(58) XL(61)

SADDLE

Velomann MITORA 149 H2 cover: soft touch, padding: foam, shell: nylon carbon rails: Steel lenght: 250mm width: 149mm
