Motor Unit
Motor
OLI Edge, 90Nm, 250W Display High Vision
Battery
Internal battery 630Wh
Frameset
Frame
E-OMNIA C-Type chain drive ALU sizes: 45-50-55 - 9x135 mm quick release dropouts - Post mount 180 disc brake type - Internal cable routing in DT - 625Wh compatible - custom rear carrier integrated in the frame design
Fork
Suntour XCM34-Boost NLO DS 29", 120mm travel, 1.5" tapered HT, w/ 15AH2-110 TA, minimum 160mm rotor, maximum 203mm rotor, 34mm stanchions, Coil w/ preload adjuster
Headset
FSA NO.55R/558 1.5"
Drivetrain
Shifters
Shimano, SL-M4100-R, DEORE, 10-SPEED
Rear Derailleur
Shimano, RD-M4120, DEORE, SGS 10/11-SPEED
Crankset
FSA CK-320/IS Die cast AL crank 170mm ISIS
Bottom Bracket
included in the motor
Chain
KMC e10S NPBK Anti-Rust
Brakes
Brakes
Promax DSK-925, Mineral Oil
Rotor
Promax DSK-925, 180mm
Wheels
Wheels
Velomann E-Sport Tubeless Ready 29", 25-622, 32 hole black
Rear Hub
Formula CL-1422 Center lock, 32hole, 14G, O.L.D. 135mm AXEL145mm, for Shimano 8/9/10speed with Quick release
Front Hub
Formula CL-811 for Center Lock, 32h, 15x110mm TA, 2SB
Tire
Vittoria e-Randonneur, 50-622
Cockpit
Stem
Velomann 31,8 size: 90mm - SM, 110mm for LG / MD
Handlebar
Velomann, 31.8*630 / Rise 34mm / Back Sweep 41°
Grips / Extensions
Herrmans Grip 130
Saddle
Seatpost
Velomann 31.6*350, suspension seatpost
Saddle
Velomann, steel rail, 254x183mm, 420gr.
Accessories
Pedals
VPE-889P, PP body, reflector included.
Mudguards
SKS PET Mudguards A65 R /28
Kickstand
Velomann load 35kg
Rear Carrier
custom rear carrier integrated into the frame design
Front Light
Spanninga custom integrated light, 40 lux
Rear Light
Spanninga custom integrated light
