FRAMESET
FRAME
Magma 29" alu, 1,1/8" HT, BSA 68mm, seatpost diam. 27,2mm, low clamp FD diam. 31,8mm bottom pull or Side-Swing, PM 160mm, dropouts 9x135mm QR, internal cable routing, sizes 15-17-19-21"
FORK
SR Suntour XCM HLO DS 29" 100mm
HEADSET
Fsa TH888
DRIVETRAIN
SHIFTERS
Shimano Alivio SL-M3100 2x9sp
REAR DERAILLEUR
Shimano Alivio RDM3100 SGS 9sp
FRONT DERAILLEUR
Shimano FD-M2020-TS low clamp diam. 31,8mm, dual pull, 64/69°, for 36T w/14T capacity, CL 48.8/51.8mm
CRANKSET
Shimano FC-MT101-2, 36/22T, crank length: 170mm-15/17", 175mm-19/21"
BOTTOM BRACKET
Shimano BB-UN101
CHAIN
Kmc HV900 9sp
CASSETTE
Shimano HG200-9, 11-13-15-17-20-23-26-30-36T
BRAKES
BRAKES
Shimano BR-MT200
ROTOR
Shimano SM-RT10, 160mm front & rear, Center Lock
WHEELS
WHEELS
VelomannDP2.5, 622x25c
REARHUB
Formula CL-1422
FRONTHUB
Formula CL-1420
TIRE
Kenda Booster 29x2.20
COCKPIT
STEM
Velomann ST92A +/-7°, 1.1/8", diam.31.8mm, ext: 80mm-15/17" and 90mm-19/21", 3D forged alloy 6061
HANDLEBAR
Velomann rise MTB479A, width 720mm, diam.31,8mm, rise 15mm, backsweep 9°, PG Alloy 6061 sandblasted anodized
GRIPS
T-one T-GP48B
SADDLE
SEATPOST
Velomann AL2014 shaft w/alloy head, diam. 27.2mm, 0mm seatback, length 350mm
SADDLE
Velomann, steel rails, PVC soft touch cover, 140mm width
ACCESSORIES
PEDALS
included
