FRAMESET
FRAME
Arcadex Carbon, 1.5" headset, seatpost diam. 31.6mm, thru axle 12x142mm, flat mount caliper, Pressfit 41 BB, compatible with 42mm tire and mudguard predisposition, sizes: XS-SM-MD-LG-XL
FORK
Bianchi Full Carbon Disc, 1.5" head, flat mount caliper, thru axle 12x100mm
HEADSET
FSA SMR HS with 1.1/8” custom top cone Bianchi, H2475, Internal Headset, Integrated Alloy custom top cup 1.1/8", 1.5", 36°/45° ACB
DRIVETRAIN
SHIFTERS
Shimano GRX 810 ST-RX810 1x11sp
REAR DERAILLEUR
Shimano RD-RX812, GRX 11sp, top normal shadow plus design, direct attachment, direct mount compatible
CRANKSET
Shimano GRX 810 FC-RX810-1 40T, Hollowtech II, Crank Length: 170mm-XS/SM, 172.5mm-MD/LG, 175mm-XL
BOTTOM BRACKET
Shimano SM-BB72-41B
CHAIN
Kmc X11-1 EPT finish
BRAKES
BRAKES
Shimano BR-RX810
BRAKELEVERS
included w/shifters
ROTOR
Shimano SM-RT70, diam. 160mm
WHEELS
WHEELS
AlexRims GD24 disc 622-21, tubeless ready
REARHUB
Shimano FH-RS470
FRONTHUB
Shimano HB-RS470
TIRE
WTB Riddler Comp 700x37
COCKPIT
STEM
Reparto Corse by Fsa ST-OS-188/SMR-0°, Alloy 6061 , 1 1/4", rise 0°, Ext: 80mm-XS/S, 100mm-M, 120mm-L/XL
HANDLEBAR
Reparto Corse Aluminum 6061, reach 70mm, flare angle 16°, drop cc 120 x size 40cm and 130mm, size: 40cm-XS/S, 42cm-M/L, 44cm-XL
GRIPS
La Spirale Ribbon cork
SADDLE
SEATPOST
Reparto Corse Alloy shaft AL6061, alloy head, 15mm offset, 31,6mm, Length: 300mm-XS, 350mm-S/M/L/XL
SADDLE
Reparto Corse 2315HRN, rail steel black, open, cover PU, lenght/wide 250x148mm
