O Oltre Pro foi projetado para pilotos exigentes que sempre se esforçam para estar na frente.
Andando em estradas pavimentadas.
FRAME
Oltre PRO carbon w/Bianchi System aero shape, electronic drivetrain only, headset 1.1/4""-1.1/4"",BB-PressFit 86,5x41mm, integrated seat clamp, for flat mount caliper, internal cable routing for brakes, thru axle 12x142mm, compatible with 700x30 tire s
FORK
Full Carbon aero w/Bianchi System, brakes, integrated head 1.1/4", flat mount caliper, thru axle 12x100mm, compatible with 700x30 tire
HEADSET
Fsa No. 54 - MR137 - ACB 1-1/4"" diam.46.9 x diam.37x7 Fsa TH970R - MR082R - SL Alloy ACB 1-1/4"" diam.46.8 x diam.34x7
STEM
Integrated handlebar Integrated Aero bar, material Carbon, drop 125mm, reach 80mm, Di2 compatible Ext: 90/400 ; 100/420 ; 110/420; 120/440
HANDLEBAR
included in the stem
| SIZE | A | B1 | C | D | E | F | G | G1 | H | I | X | Y | WB |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 470 | 450 | 515 | 410 | 58 | 83 | 579 | 74.5° | 70.5° | 43 | 368 | 385 | 470 | 982 |
| 500 | 480 | 525 | 410 | 58 | 88 | 581 | 74.5° | 71.5° | 43 | 368 | 392 | 478 | 983 |
| 530 | 510 | 536 | 410 | 68 | 103 | 582 | 74° | 72° | 43 | 368 | 393 | 504 | 984 |
| 550 | 530 | 550 | 410 | 68 | 118 | 588 | 73.5° | 72.5° | 43 | 368 | 397 | 520 | 988 |
| 570 | 550 | 560 | 412 | 68 | 133 | 593 | 73.5° | 73° | 43 | 368 | 402 | 536 | 996 |
| 590 | 570 | 575 | 412 | 68 | 153 | 603 | 73° | 73° | 43 | 368 | 406 | 555 | 1005 |
