A imagem apresentada é apenas indicativa.
Os componentes e detalhes gráficos podem diferir do modelo real.
Preço de referência, pode sofrer alteração na cotação.
Pilotos experientes e para quem está iniciando a carreira de piloto
Andando em estradas pavimentadas.
FRAME
Sprint carbon monocoque, mechanical/electronic, BB-PressFit 86,5x41, head tube 1.4"-1.5", integrated seat clamp, full carbon dropout, Disc brake flat mount, thru axle 12 x 142 sizes 47-50-53-55-57-59-61cm
FORK
Full Carbon Aero Road 1.4">1.5" integrated head , Disc brake flat mount, thru axle 12x100
HEADSET
ACROS & FSA, for internal cable routing
SHIFTERS
Shimano 105 Di2, RD-R7150 12-speed
REAR DERAILLEUR
Shimano, RD-R7150, 105 Di2 12-speed
FRONT DERAILLEUR
Shimano 105 Di2, FD-R7150 12-speed
CRANKSET
Shimano 105 12sp, FC-R7100, for rear 12- speed, Crank Length: 170mm-47/53cm, 172.5mm-55/59cm, 175mm-61cm
BOTTOM BRACKET
Shimano, SM-BB72-41B, press fit for road
CHAIN
Shimano 12sp, CN-M7100
BRAKES
Shimano, BR-R7170 Hydraulic disc brake, included in the shifter
ROTOR
Shimano rotor for disc brake center lock, SM-RT70, 160mm
WHEELS
Velomann alloy, disc brake, 30mm rim profile, hub team TC j-bend, spoke round 2mm black color, clincher 622x19C, w/rim tape, front HH12 - rear HH12/142
TIRE
Vittoria Rubino IV G2.0 graphene, 700x25, 60TPI
STEM
Velomann, Alloy 6061, raise - 7° Ext: 80mm-44cm, 90mm-47/50cm, 100mm-53cm, 110mm-55/57cm, 120mm-59/61cm
HANDLEBAR
Velomann Compact, alloy 6061, diam. 31,8mm, reach 80mm, drop 130mm Size: 400mm-44/53cm,420mm-55/59cm,440mm-61cm
GRIPS
Bianchi cork, black
SEATPOST
Velomann alloy 6061, 15mm offset, 27,2mm; Length: 300mm-44cm ; 350mm-47/61cm
SADDLE
Velomann Seta
SIZE | A | B | C | D | E | F | G | G1 | H | I | X | Y | WB |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
470 | 420 | 515 | 410 | 60 | 105 | 580 | 74.5° | 70.5° | 43 | 373 | 377 | 497 | 982 |
500 | 450 | 525 | 410 | 60 | 110 | 582 | 74.5° | 71.5° | 43 | 373 | 383 | 505 | 983 |
530 | 480 | 535 | 410 | 68 | 125 | 583 | 74° | 72° | 43 | 373 | 384 | 529 | 984 |
550 | 500 | 550 | 413 | 68 | 140 | 588 | 73.5° | 73° | 43 | 373 | 388 | 545 | 991 |
570 | 520 | 560 | 413 | 68 | 155 | 593 | 73.5° | 73° | 43 | 373 | 393 | 561 | 996 |
590 | 540 | 575 | 413 | 68 | 175 | 603 | 73° | 73° | 43 | 373 | 396 | 580 | 1006 |
610 | 560 | 585 | 415 | 68 | 195 | 607 | 72.5° | 73° | 43 | 373 | 397 | 599 | 1012 |
