Granfondo e pilotos esportivos de longa distância. Para quem adora passar muitas horas na selim.
Andando em estradas pavimentadas.
FRAME
INFINITO Carbon-CV, Disc Brake, Mechanical/Electronic Di2/EPS, TC19, compatible with 32" tire, BBset pressfit 86,5x41, rear dropout 12 x 142mm thru axle, sizes 47-50-53-55-57-59-61cm
FORK
Full Carbon-CV - 28"-300mm - 1,5" Disc Brake, flat mount, thru axle 12x100, compatible with 32" tire
HEADSET
FSA NO.42/47CF/ACB/5D, 1-1/8 ACB Top, 1.5" ACB Btm
SHIFTERS
Shimano 105 hydraulic disc brake for road
REAR DERAILLEUR
Shimano 105 Di2, RD-R7150, W/TL-EW300
FRONT DERAILLEUR
Shimano 105 Di2, FD-R7150, top gear 50-52T
CRANKSET
Shimano 105 Di2, FC-R7100, Ultegra hollowtech 2, 170-172,5-175mm, 50x34T, crank lenght: 170mm-47/53cm, 172.5mm-55/59cm, 175-61cm
BOTTOM BRACKET
Shimano SM-BB72-41B, press fit for road
CHAIN
Shimano 105 Di2, CN-M7100
BRAKES
Shimano BR-R8170 Hydraulic disc brake, included in the shifter
ROTOR
Shimano SM-RT70 rotor for disc brake center lock, S 160mm w/lock ring (2pcs)
WHEELS
Vision Trimax 30 disc brake 700X19c, Hubs SC ,clincher, front 12X100 - rear 12X142 HG
TIRE
Pirelli P7, 700 x 28c, 60TPI
STEM
Reparto Corse, 3D Forged alloy 6061, raise +/ - 7°, height 38mm, Oversize, 1 1/8", 1 piece alloy faceplate 6061, size 70-90-100-110-120mm, Ext: 70mm-47cm, 90mm-50cm, 100mm-53cm, 110mm-55cm, 120mm-57cm/61cm
HANDLEBAR
Reparto Corse Compact Flat Top, alloy 2014 diam. 31,8mm, reach 80mm, drop 130mm, Sizes: 40-42-44, Size: 400mm-47/50cm , 420mm-53/57cm, 440mm-59/61cm
GRIPS
Velo Black soft Microfiber tapes+EVA-139 Shockproof 200*3cm with 4 line hole Black/Celeste color and VLP-56 BK plug
SEATPOST
Reparto Corse Full Carbon special dimension; lenght: 350mm-47 /57cm; 380mm-59/61cm
SADDLE
Fi`zi:k Argo Tempo R5 150mm black wing flex, rail S alloy
A1 | A | B1 | C | D | E | F | G | G1 | H | I | X | Y | WB |
470 | 420 | 515 | 415 | 68 | 120 | 581 | 74.5° | 70.5° | 43 | 375 | 370 | 521 | 986 |
500 | 450 | 525 | 415 | 68 | 135 | 583 | 74.5° | 71.5° | 43 | 375 | 375 | 539 | 988 |
530 | 480 | 535 | 415 | 68 | 150 | 588 | 74° | 71.5° | 43 | 375 | 376 | 553 | 993 |
550 | 500 | 550 | 415 | 68 | 165 | 593 | 73.5° | 72° | 43 | 375 | 381 | 569 | 999 |
570 | 520 | 560 | 415 | 68 | 180 | 599 | 73.5° | 72.5° | 43 | 375 | 386 | 585 | 1004 |
590 | 540 | 575 | 420 | 68 | 195 | 608 | 73° | 72.5° | 43 | 375 | 392 | 599 | 1018 |
610 | 560 | 585 | 420 | 68 | 210 | 612 | 72.5° | 72.5° | 43 | 375 | 392 | 614 | 1023 |
