DESENHADO PARA

Um enduro e-MTB pronto para enfrentar qualquer desafio que sua pista apresente: singletrack S3, S4 ou S5? Sua paixão não conhecerá limites.

CONDIÇÕES DE CONDUÇÃO

Andar em terrenos acidentados com quedas inferiores a 122 cm.

MOTOR UNIT

MOTOR

Bosch Performance Line CX, 250W, 85Nm, Kiox display

BATTERY

Bosch PowerTube 750Wh integrated battery

FRAMESET

FRAME

e-VERTIC FX-Type Pro - full carbon sizes: 43, 48, 53 - 12x148 mm thru axle dropouts - Post mount 180 disc brake type - 160mm travel front & rear - Internal cable routing in steerer

FORK

Fox 38 Float eBike optimized 29", Performance, 160mm travel, 1.5" tapered HT, Kabolt 15x110mm BOOST axle, minimum 180mm rotor, maximum 230mm rotor, 44mm rake, 58mm crown, GRIP, 3 position lever

REARSHOCK

FOX Float X2, Factory, 230/65, EVOL, 2 position lever, 0.3 Spacer x2, Neutral Decal

HEADSET

Acros AIX-545 1.8" top / 1.5" - internal cable routing

DRIVETRAIN

SHIFTERS

Sram AXS Pod Controller

REAR DERAILLEUR

Sram GX Eagle AXS, 12sp

CRANKSET

FSA CK-320/IS/Gen4 FSA E-Bike Diecast Crankset ISIS / 165mm / Die cast aluminum Sram Eagle Chainring, 34T

BOTTOM BRACKET

included in the motor

CHAIN

Sram GX EAGLE, 12sp

BRAKES

BRAKES

Magura MT7 4 pistons

ROTOR

Magura MDR-P Centerlock - 203 m

WHEELS

WHEELS

Velomann Tubeless Ready 29", 622x30, 32 hole

REARHUB

Formula CL-3248 for Center Lock, 32h, 12x148mm TA

FRONTHUB

Formula CL-811 for Center Lock, 32h, 15x110mm TA

TIRE

Vittoria e-Barzo 29x2.6 XC-Trail TNT

COCKPIT

STEM

Velomann, 50mm, 35mm, 1"1/8

HANDLEBAR

Velomann, width 780mm, diam.35mm, rise 18mm, backsweep 8°

GRIPS

T-One Rock T-GP34 single lock grip, TPR, 130mm, plastic inner body, aluminium clamp

SADDLE

SEATPOST

Velomann, diam.31,6mm, internal remote cable routing, 120mm/150mm travel - 120mm for size 43

SADDLE

Velomann Gnd Full-fit Start Up, carbon steel rail, 262x145
