MOTOR UNIT
MOTOR
Mahle X35 Plus 250W motor unit, iWOC One remote control, BLE and ANT+ compatible
BATTERY
Mahle X35+ 250Wh
FRAMESET
FRAME
E-Road Aria aero carbon, mechanical/electronic, BB-PressFit 86,5x41, head tube 1.4"-1.1/8", integrated seat clamp, full carbon dropout, aero shape DT-ST, Disc brake flat mount, QR sytem, OLD 135mm sizes 47-50-53-55-57-59-61cm
FORK
Full Carbon Aero Road 1.4">1.1/8" integrated head , Disc brake flat mount, thru axle 12x100
HEADSET
FSA Orbit C-33, NO.44E, 1-1/8
DRIVETRAIN
SHIFTERS
Shimano DISC BRAKE SET, 105, ST-R7170
REAR DERAILLEUR
Shimano, RD-R7150, 105,12-SPEED
FRONT DERAILLEUR
Shimano, FD-R7150, 105
CRANKSET
Shimano, FC-R7100, 105, 50-34T Crank Length: 47-50-53 - 170mm 55-57-59 - 172.5mm61L - 175mm
BOTTOM BRACKET
Shimano,SM-BB72-41B, PRESS FIT TYPE FOR ROAD, BEARING, INNER COVER
CHAIN
Shimano, CN-M7100, HG 12-SPEED
BRAKES
BRAKES
Shimano included in the shifter
ROTOR
Shimano, SM-RT86, S 160MM
WHEELS
WHEELS
FSA Vision Trimax alloy disc with rear Mahle motor hub
REARHUB
FSA Vision Trimax alloy disc with rear Mahle motor hub
TIRE
Vittoria Rubino Pro G2.0 graphene, 700 x 28c, 150TPI
COCKPIT
STEM
Velomann, raise - 6°, height 38mm, Oversize, 1 1/8", size 90/100/110/120cm Ext: 90mm-48/50cm, 100mm-52/54cm, 110mm-56cm, 120mm-58cm
HANDLEBAR
Velomann, Flat Top, alloy 6061 diam. 31,8mm, reach 80mm, drop 130mm Size: 400mm-44/53cm, 420mm-55/59cm, 440mm-61cm
GRIPS
La Spirale Ribbon cork
SADDLE
SEATPOST
Full Carbon Aero special dimension, special Clamp type with alloy head adjustable and reversible +/- 35mm; lenght: 300mm - 47/50cm; 350mm - 53/61
SADDLE
Velomann, carbon steel rail, 262x145
