DESENHADO PARA

Alimente seu desejo de explorar, esforçando-se cada vez mais.

CONDIÇÕES DE CONDUÇÃO

Andar em estradas pavimentadas e não pavimentadas com desníveis inferiores a 15 cm.

MOTOR UNIT

MOTOR

Bosch Performance Line CX, 85Nm, Kiox display

BATTERY

Bosch Powertube 500Wh integrated battery

FRAMESET

FRAME

e-Arcadex Carbon sizes: 47, 51, 55, 58, 61 - 12x142 mm thru axle - Flat mount 140 disc brake type - Fender compatible

FORK

Full Carbon 1.5" flat mount, disc brake, thru axle 12x100mm

HEADSET

FSA SMR HS with 1-1/8”

DRIVETRAIN

SHIFTERS

SRAM Apex Disc Brake

REAR DERAILLEUR

SRAM Apex XPLR

CRANKSET

FSA E-bike Crankset / 165mm - 170mm - 175mm / Hollow Alloy FSA Alloy 42T

BOTTOM BRACKET

Included in the Drive unit

CHAIN

SRAM Apex

BRAKES

BRAKES

Sram included in the shifter

ROTOR

Sram Paceline, Center lock, 160mm

WHEELS

WHEELS

Velomann, 23-622, profile 24,5mm, 32hole, tubeless ready

REARHUB

Formula RXC-142S road disc , center lock, J-bend, thru axle 12x142mm

FRONTHUB

Formula CL-712 road disc , alloy 32h, center lock, J-bend, thru axle 12x100mm

TIRE

Continental 40-622 Terra Trail

COCKPIT

STEM

Velomann, Alloy 6061 , 1 1/4", raise 0° Ext: 80mm-XS/S, 100mm-M, 120mm-L/XL

HANDLEBAR

Velomann Aluminum 6061, reach 70mm, flare angle 16°, drop cc 120 x size 40cm and 130mm x size 42-44-46cm Size: 400mm-XS/S, 420mm-M/L, 440mm-XL

GRIPS

La Spirale Ribbon cork

SADDLE

SEATPOST

Velomann Alloy shaft, alloy head, 15mm offset, 31,6mm Length: 300mm/XS - SM ; L350mm/MD - LG -XL

SADDLE

Velomann, carbon steel rail, 262x145

ACCESSORIES

MUDGUARDS

SKS A46 profile, integrated tail light XELTEC, 12V

REARCARRIER

SKS Infinity GT3

FRONTLIGHT

Supernova Mini2 - 235 lumen - 4 W a 12 V

REARLIGHT

Integrated in the mudguard
