A imagem apresentada é apenas indicativa.
Os componentes e detalhes gráficos podem diferir do modelo real.
Preço de referência, pode sofrer alteração na cotação.
Alimente seu desejo de explorar e se esforçar cada vez mais.
Andar em estradas pavimentadas e não pavimentadas com desníveis inferiores a 15 cm.
MOTOR
Bosch Performance Line CX motor unit
BATTERY
Bosch Powertube 500Wh integrated battery
FORK
Full Carbon 1.5" flat mount, disc brake, thru axle 12x100mm
HEADSET
FSA SMR HS with 1-1/8” custom top cone Bianchi, H2475 Internal Headset, Integrated Alloy custom top cup 1.1/8"", 1.5"", 36°/45° ACB
SHIFTERS
Campagnolo EP EKAR 1x13 - Ant. adapter + screws - Post. adapter + screws - Fixing screws 29mm
REAR DERAILLEUR
Campagnolo RD EKAR 1x13
CRANKSET
FSA E-bike KFX Crankset - ISIS / 165mm - 170mm - 175mm / Hollow Alloy / SB black FSA Bosch Gen4 STD Alloy Spider
BOTTOM BRACKET
Included in the Drive unit
CHAIN
Campagnolo EKAR 13v C-Link 117 links w/quick-link
BRAKES
included in the shifter
BRAKELEVERS
included
ROTOR
Campagnolo AFS 160mm, steel spider
REARHUB
TA 12x142, center lock, J-bend, N3W
FRONTHUB
TA 12x100, center lock, J-bend
TIRE
Pirelli Cinturato GRAVEL Adventure M, 40-622, black, 60tpi, TLR, Foldable
STEM
Velomann, Alloy 6061 , 1 1/4", raise 0°, Oversize, plastic adaptor for hose cover 1 1/4", Ext: 80mm-XS -S, 100mm-M, 120mm-L/XL
HANDLEBAR
Velomann Aluminum 6061, reach 70mm, flare angle 16°, drop cc 120, Size: 400mm-XS/S, 420mm-M/L, 440mm-XL
GRIPS
La Spirale Ribbon cork + new plug carbon look with Bianchi logo color: Black
SEATPOST
Alpha3 Series, 40+80, 31,6 mm, Anodized black, Gravel remote, 1800 mm Barrel + screw
SADDLE
Velomann, rail steel black, open, cover PU, lenght/wide 250x148mm color: black
SIZE | A | B1 | C | D | E | F | G | G1 | H | I | X | Y | WB |
XS | 440 | 520 | 434 | 70 | 125 | 596 | 74.5 | 70.5 | 50 | 416 | 364 | 564 | 1020 |
SM | 480 | 532 | 434 | 70 | 140 | 603 | 74 | 70.5 | 50 | 416 | 366 | 579 | 1028 |
MD | 520 | 548 | 434 | 70 | 155 | 609 | 73.5 | 71 | 50 | 416 | 372 | 594 | 1034 |
LG | 550 | 563 | 434 | 70 | 170 | 625 | 73.5 | 71 | 50 | 416 | 382 | 609 | 1049 |
XL | 580 | 583 | 434 | 70 | 185 | 640 | 73 | 71 | 50 | 416 | 392 | 623 | 1064 |
